TECHNICAL SPECIFICATION:

• Material: Metal
• Power: 1000W
• Dimensions: 25 X 21 X 30cm
• Voltage: AC 220V 50HZ
• Weight: 6kg

• 1 x Vacuum Former Machine
• 1 x Manual

• Setup: Place the Unident Imported Vacuum Former on a stable and level surface in your dental laboratory.
• Power On: Connect the machine to a power source and turn it on. Allow it to reach the desired operating temperature.
• Select Thermoplastic Material: Choose the appropriate thermoplastic sheet based on the type of dental appliance you intend to create. Ensure the sheet is trimmed to the required size.
• Secure the Material: Place the trimmed thermoplastic sheet over the model or mold you wish to use. Ensure it is evenly distributed and properly secured.
• Heating Process: Position the model with the thermoplastic sheet into the heating area of the machine. Activate the heating element to soften the thermoplastic material. Follow recommended heating times and temperatures.
• Vacuum Forming: Once the thermoplastic material is adequately heated and pliable, move the model to the vacuum forming area. Activate the vacuum function to mold the softened material over the model.
• Cooling: Allow the formed material to cool and solidify. This can be expedited using a cooling fan or other cooling methods.
• Remove the Formed Appliance: Carefully remove the vacuum-formed dental appliance from the model. Ensure that the material has completely set and hardened.
• Trimming and Finishing: Trim any excess material from the formed appliance and perform any necessary finishing touches to achieve the desired shape and contours.
• Clean and Maintain: Clean the machine and remove any residual material. Follow the manufacturer's guidelines for maintenance to ensure the longevity of the Unident Imported Vacuum Former.
• Power Off: Turn off the machine and disconnect it from the power source.
